Import a Collar Survey

You can import collar surveys from an external system if the data is in a .csv or .txt file. See File Formats.

This video, recorded using an earlier version of DataBlast Pro, provides an example of how to import collar survey data.

Activity Steps

  1. Select the Drill module.
  2. Select a drill pattern in the DataBlast Items Tree.

    The drill pattern displays in the Viewport.

  3. Either select the drill pattern boundary or a subset of the holes. See Select Objects in the Viewport.
  4. On the Drill Ribbon Menu, click Import Collar Survey.

    The Collar Survey Import screen displays.

  5. Click the ellipsis (...) to browse for and select the data file in .csv or .txt format.

    The data displays as a table.

    Note: This file should contain one row or line of data per hole. The expected data is the hole ID and the coordinates of its collar location. There should not be a row with column headers.

  6. Update the following parameters as required.
    • Field Delimiter—Select from Comma, Tab, Semicolon and Space; or enter a character for Other.
    • Decimal Separator—Select from Period and Comma; or enter a character for Other.
    • Thousands Separator—Select from None, Period and Comma; or enter a character for Other.
    • Unit of Measure—Select from Millimetres, Centimetres, Metres, Kilometres and Feet.
  7. For each column in the table, right-click the column header area and select the data type from:
    • Hole ID
    • Easting (X)
    • Northing (Y)
    • RL (Z)

    Note: Columns without a selected data type are not imported.

  8. Click Import.

    Note: If a hole in the imported data has not yet been flagged as drilled, the Action Date/Time screen displays with options to set the drilled date and time. See Change the Drilled Status of Holes.

  9. Click Save Changes.
