Format Section Line Dialog |
Format Section Line Dialog
Choose |
To Do This |
Appearance |
|
Color |
Select color. |
Hide |
Toggle yes/no for hiding or showing the Section Line. |
Line Style |
Select line style (Active when Hide = No). |
Only display in 3d views |
Toggle yes/no to display only in 3d views or all views. |
Show all sections |
If enabled, an indication of all sections that transect the current projection will be indicated. If disabled, only the currently defined section will be shown. |
General |
|
Share |
Select whether to share within the selected sheet, within the document or not at all. |
Limits |
|
Fit to data |
Set the size of the section line to fit the data. Set to no to change the following definitions. |
X From |
Set minimum X co-ordinate of data. |
X To |
Set maximum X co-ordinate of data. |
Y From |
Set minimum Y co-ordinate of data. |
Y To |
Set maximum Y co-ordinate of data. |
Z From |
Set minimum Z co-ordinate of data. |
Z To |
Set maximum Z co-ordinate of data. |
Mid Point |
|
X Mid |
Set the X co-ordinate of mid point. |
Y Mid |
Set the Y co-ordinate of mid point. |
Z Mid |
Set the Z co-ordinate of mid point. |
Span |
|
X Span |
Specify the range of the X co-ordinates. |
Y Span |
Specify the range of the Y co-ordinates. |
Z Span |
Specify the range of the Z co-ordinates. |
