Control Limit Styles

The Control Limit Styles Screen provides a central place to configure the visual style of control limits used in Reconcilor analysis screens. A control limit style defines how control limits display on charts and how tolerance bands display on continuum ribbons and table cells.

Each control limit style has two parts. Chart Lines defines the line style and colour used for the first and second control limit lines on charts. Continuum and Table Cell Colouring defines the colours used above, within, and below the configured control limits.

Control limit styles define appearance only. They do not define the control limit values themselves. The configured values are defined in Comparison Calculations, where a control limit style can then be assigned to individual measures, grades, or attributes.

You can create multiple control limit styles to support different visual conventions for different comparison types.
